850MHz / 900MHz GPRS GSM Waterproof Motorcycle GPS Trackers
Environment-friendly PVC 850MHz / 900MHz GPRS GSM Waterproof Motorcycle GPS Trackers
Summarization
This model is the GPS vehicle tracking device which designed based newest 3G(GIS, GPS, GSM) technology. Aim at market demand, combined years experiences in design, testing, production control and other sides, according with the automobile inductry’s strict requirements to vehicle electronical equipments, use reliability theory, adopt dynamic, redundancy, derating and other design methods to ensure the quality of circuit; adopt high-performanced, industrial components to ensure the quality of this model. Application fields: logistics vehicle, rental vehicle, passenger transport, freight transport, taxi, ship, bus, private car, motor and etc.
1. Configuration
Standard configuration: GPS main device, panic button, installation cables.
Optional accessories: built-in backup battery, relay for stop engine, buzzer.
2. Product parameters
Main device technical parameters:
Name |
Parameters |
Remarks |
Working voltage |
7~50V/DC |
|
Working temperature |
-20℃~+70℃ |
|
Working humidity |
5%~95% |
|
Anti-reverse connection |
≥80V |
|
Working current |
Working status (average) : 35mA @ DC 12V; Power save status: <20mA @ DC 12V |
|
Power |
Working status0.42 w; sleep mode 0.18 w |
|
Size |
L*W*H : 85*60*33.5MM or 109*60*33.5MM (with mounting hole) |
|
Casing material |
Environment-friendly PVC |
|
Net weight |
160 g |
|
GSM/GPRS performance |
Communication frequencies: 850MHz/900MHz/1800MHz/1900MHz |
|
Communication mode: GSM, GPRS(TCP/UDP) GPRS multi-slot class 10; downlink: max 85.6Kbps GPRS multi-slot class 8 GPRS mobile station class B Uplink speed: max 42.8Kbps |
|
|
Satisfied GSM 2/2+ standard: Class 4(2w@850/900MHZ) Class 1(1w@1800/1900MHZ) |
|
|
GPS performance |
SiRF star III, support WAAS |
|
Frequency:L1, 1575.42MHZ |
|
|
GPS sensitivity: -159db |
|
|
Channels: 20 |
|
|
Positioning time: cold start less than 42s; |
|
|
Hot start: average 1s; |
|
|
Warm start: average 38s |
|
|
Recapture: 0.1s |
|
|
Positioning accuracy: 10m 2D RMS |
|
|
Speed precision: 0.1m/s |
|
|
Height: <18, 000m |
|
|
Speed: <515m |
|
|
GPS antenna |
Built-in |
|
GSM antenna |
Built-in |
|
Vehicle detecting interface |
2 signal input: ACC detecting, SOS alarm |
|
AD detecting interface |
1 AD detecting: detect the voltage of external battery (power supply) |
|
Voice interface |
1 microphone listen in port |
|
Built-in battery |
Built-in high capacity lithium battery: 800mA |
Working time:24h |
3. Product functions
Ø Waterproof: waterproof standard IP65.
Ø Illegal towing alarm:it will send alarm to mobile phone or software platform when vehilce is force to tow-away.
Ø Crash alarm: when vehicle is in parking, device will send vibration alarm to software platform or authorized mobile phone if there is crash with the vehicle.
Ø ACC switch detecting: detect ACC switch, and control data transmission based the status of ACC switch, like uplink data when ACC is On, do not uplink data when ACC is Off.
Ø Inquire location on GOOGLE map: GOOGLE map link of vehicle’s current location will be added when there is alarm generate and send out, user can press this link to check the detailed location while alarm is generated.
Ø SOS alarm: if user need, press SOS then there is SOS alarm be send to software platform and authorized mobile phone.
Ø Speeding alarm: GPS device will send speeding alarm to software platform or authorized mobile phone if vehicle’s speed exceed the set value.
Ø Alarm of enter into/out of limit area:when target enter into or out of the prohibited area set by administrator, GPS device will send alarm to software platform or authorized mobile phone.
Ø Power lost alarm: GPS device will send alarm to software platform and authorized mobile phonewhen someone artificially dismantle the device’s power.
Ø External battery low voltage alarm: GPS device will send alarm of low power to software platform when vehicle battery is lower to a certain value.
Ø Stolen alarm: device detected vehicle is stolen, it will send alarm to software platform and authorized mobile phone.
Ø Remote stop engine: software platform or mobile phone control to stop engine.
Ø Listen in: when there is alarm or it is needed, can listen in the voice around the GPS device.
Ø Supplemental report for GSM blind area: when the GSM signal is not good enough, GPS device will store positioning data and alarm information, and send out once the signal is good enough.
Ø Mobile phone to inquire location: administrator and authorized mobile phone send command to the GPS device can get target’s location.
Ø Administator, authorized number setting:after administrator or authorization number is set, can receive various of alarm, target’s location, do setting with GPS device, other mobile phone number can not do it.
Ø Password: use mobile phone to set and operate GPS device, it needs input correct password.
Ø Mobile phone mode or software platform mode: user can change software platform mode to mobile phone mode, GPS device will send all information to mobile phone.
Ø Parameters modification via SMS: administrator or authorized number can modify devices’ various of parameters via SMS.
Ø Report vehicle’s status: real time monitor various kinds of status of vehicle, like moving speed, directions, longitude, latitude, ACC...
Ø Tracking and monitoring: real time track and monitor the targets which installed GPS devices.
Ø Update remotely: can update GPS device’s firmware remotely if needed.
Ø Debugging remotely: when GPS device has faults, can analyse and handle the faults remotely.
Ø Restore to factory setting: can use factory setting command to restore the device to initial state if needed.
