VT300 AVL GPS Vehicle Tracker with SMS/GPRS for Car /Truck
1.Current location report
2.Built-in motion sensor for power saving
3.Geo-fencing control, Low battery alert
4.Speeding alert Engine
5.Alert when TK508 enters/exits GPS blind area
6.Alert when TK508 is turned on
7.I/O: 5 digital inputs, 3 negative and 2 positive triggering; 5 outputs.
8.Analog Input: 2 10 bits resolution analog inputs
GPS TRACKER SPECIFICATION
1, GSM communication and alarm report;
2, SMS message and alarm report;
3, GPRS:communication, tracking and alarm report;
4, GPS:position and tracking;
5, Position preservation;
6, Fuel consumption report, mileage management;
7, Temperature report, driving state management;
8, Output control, car doors, engines and other states.
9, Electronic fences and all kinds of alarm functions;
10, Support calling by external controller and microphone
11, Support the COM port to connect external display ads or other serial devices
Power Supply +9V - +35V / 1.5A
Backup Battery 850mAh
Dimension 104mm x 62mm x 24mm
Installation Dimension 104mm x 83mm x 24mm
Operating temperature -20° to 55° C
Humidity 5% to 95% Non-condensing
Frequency GSM 900/1800/1900Mhz or GSM 850/900/1800/1900Mhz
GPS Module High sensitivity GPS receiver
GPS Sensitivity -159Db
GPS Frequency L1, 1575.42 MHz
C/A Code 1.023 MHz chip rate
Channels 20 channel all-in-view tracking
Position Accuracy 10 meters, 2D RMS
Velocity Accuracy 0.1 m/s
Time Accuracy 1 us synchronized to GPS time
Default datum WGS-84
Reacquisition 0.1 sec., average
Hot start 1 sec., average
Warm start 38 sec., average
Cold start 42 sec., average
Altitude Limit 18, 000 meters (60, 000 feet) max.
Velocity Limit 515 meters/second (1000 knots) max.
LED 2 LED lights to show GPS/GSM working status.
Flash Memory 8MB
Interface 5 digital inputs, 3 negative and 2 positive triggering; 2 analog inputs; 5 outputs.
Main Unit, GPS Antenna, GSM Antenna,
Wires, USB Cable with converter
CD including, User Manual
TK508 is a GSM/GPRS/GPS tracker device which is specially developed and designed for vehicle real-time tracking and management. With superior GPS and GPRS modules, This gps tracker has good sensitivity and stable performance. It can get accurate GPS fix even in remote places.
