RJ45 GPS Alarm EDGE DVR 4 Channel Digital Video Recorder Support PTZ For Business Car

China RJ45 GPS Alarm EDGE DVR 4 Channel Digital Video Recorder Support PTZ For Business Car supplier
RJ45 GPS Alarm EDGE DVR 4 Channel Digital Video Recorder Support PTZ For Business Car supplier RJ45 GPS Alarm EDGE DVR 4 Channel Digital Video Recorder Support PTZ For Business Car supplier

Large Image :  RJ45 GPS Alarm EDGE DVR 4 Channel Digital Video Recorder Support PTZ For Business Car

Product Details:

Place of Origin: China
Brand Name: Vicord
Certification: CE,ROHS, FCC
Model Number: MDVR-C11043G

Payment & Shipping Terms:

Minimum Order Quantity: 200pcs
Price: Negotiation
Delivery Time: 2 weeks for PO with sales forecast ; 4 weeks for PO without sales forecast
Payment Terms: T/T ; 30% prepayment upon PO release and balance to be paid before shipment
Supply Ability: 50000 Pcs/Year
Contact Now
Detailed Product Description

RJ45 GPS Alarm EDGE DVR 4 Channel Digital Video Recorder Support PTZ For Business Car



Features:

  •  Special Function: Mobile Data, GPS Data, Wide Voltage, WIFI/3G, mobile DVR player, central manage client software, SDK etc...
  •  Compression Algorithm ideal: H.264 Main Profile
  •  Playback quality: 4ch Full D1 playback synchronous;8ch D1 non-realtime or under 2ch D1 +6ch CIF realtime record,Multiple channels realtime playback synchronous
  •  Main and Sub Stream: Dual Stream, Main stream is for local record , sub stream is for network transmission.
  •  Mobile monitor: Support iPhone, Windows Mobile, BlackBerry, Symbian,Android mobile monitor
  •  Display: Support TV, VGA, HDMI(optional) output at the same time.
  •  Operation interface: Similar with WINDOWS, easy and convenient to operate it.
  •  Network: Powerful Network service(Support DAS, DHCP, PPPOE, FTP, DNS, DDNS, NTP, UPNP, EMAIL, IP permissions, IP search, ALARM CENTER etc...), WEB, mobile CMS, SDK...
  •  Browsers: Support IE, Chrome,Firefox and Safari.
  •  Remote Access: Built-in DDNS(ARSP),dyndns,oray, myq-see, no-ip etc....
  •  Differentiation: boot screen free replacement,twenty multinational language,more than ten kinds of GUI interface,ten kinds of remote control,dozens of key-press panel for combination selection,easy to achieve product differentiation.
  •  Others: With the sound system for the protection circuit, unique triple watchdog function, very low power consumption, to ensure the equipment never be hang up. With the unique black box technology, can monitor the whole run process of the equipment, can greatly reduce the maintenance costs.

Ø 4 channel Video Input

Ø support 2*SD Cardtorage;(2*SD maximum 128G)

Ø support GPS, not support Wifi/3G





Specification:

  Model MDVR-C11043G
System CPU High performance embedded microprocessor HuaWei HI3515
Operation System Embedded LINUX
System Resource Multiple channels realtime recording,playback,network operation and USB backup
Screen User Interface GUI,on-screen menu tips
Screen Display 1/4 screen
Video Standard PAL(625 line,50f/s); NTSC(525 line,60f/s)
Compression H.264(Main Profile)
Display Quality TV: D1
Playback Quality D1/HD1/CIF/QCIF
Encode Capacity

100/120fps D1


Decode Capacity 50/60fps D1
Motion detect Zones:396(22*18)detection zones,Sensitivity:1-6(6 is highest)
Audio Compression G711A
Talk back Support

Record
&
Playback

Record Mode Manual>Alarm>Video Detection>Timing
Local Playback 1~4 channels
Record Search Time/Date,Alarm,Motion Detection & exact search(accurate to second)

Storage
&
Backup

HDD Occupation

Video: CIF 4~5G/day/channel, D1 16~20G/day/channel
Audio: 691.2M/day/channel

Record Storage Local HDD,Network, SD card
Backup Mode Network/USB movable HDD/USB DVD-RW/SATA DVD-RW/SD card
Interface Video Input 4ch
Video Output 1ch BNC
Audio Input 4ch
Audio Output 1ch RCA(200-3000mV,5K)
Alarm Input 4ch(multiplexing car signals)
Alarm Output 1ch
Network RJ45 10M/100M
PTZ 1 RS485
USB 1 USB
SD card 2 SD card (Max 2 x 32G,for regular record,redundancy record, backup, snapshot etc...)
GPIO Support speed,turn light,brake signals input;vehicle information OSD overlay,storage etc...
Mobile Interface and Function GPS Support
WIFI Not support
3G Not support
  Others Support timing and delay boot up/shut down
Complement Player Mobile DVR player,support google map,show vehicle running track and data
Platform Support auto registration, no need router mapping,support google map,show vehicle running track and data
SDK Free SDK for second development
Others Power Supply Wide voltage input 6V~40V
Dimension 170mm * 139mm*40mm
Weight 730g
